Description
The DC Powered Vacuum Glass Lifter ARGL-500DC is suitable for lifting and transporting glass elements of up to 500kg.
The upgraded DS Glass Lifter is also available.
This device can be used to install windows and large glass sheets with the aid of a forklift, counterbalance crane or overhead hoist. On-board DC power systems provide cord-free operation at the job site. Movable vacuum pads and extension arms allow the DC Powered Vacuum Glass Lifter – ARGL-500 to handle glass in nearly every size and shape.
Features
- Spring-loaded vacuum pads.
- Manual rotation of 360° with 45° step.
- Manual tilting by 90° in 15° grid.
- Removable arm – depth minimum 150mm.
- Integrated vacuum reservoir tank.
- Integrated instrumentation for monitoring the vacuum and the energy supply.
- Visual and audible warning devices.
- Self-contained 12-volt battery power supply with high capacity
- Extension arms allow the handling of large-sized sheets.
- Adjustable arms.
Specifications
| Metric (mm-kg) | Imperial (inch-lb.) | |
| Number of pad | 4 | – |
| Pad diameter | 300 | 11.8″ |
| Working load limit | Vertical: 400 Horizontal: 500 |
882 1102 |
| Net weight | 69 | 152 |
| Gross weight | 95 | 209 |
| Packaging dimensions | L.1070xW.970xH.450 | 42.1″x38.2″x17.5″ |
- Battery information for the lifter
| Code battery | M12B6 Milwaukee |
| Type of battery | Lithium-ION |
| Voltage | 12V |
| Current | 6.0Ah |
| Quantity | 1 |
| Continuous operation time | 2 hours |
| Working time | 6 hours |
- Battery information for charger
| Code battery charger | C12C Milwaukee |
| Input supply voltage | 100-240VAC |
| Output voltage | 12V |
| Output current | 3.0Ah |
| Quantity | 1 |
| Fully charger time | 2.5 hours |
| Weight | 460 gram |
- Motor information
| Vacuum flow rate | 32.5 liters/minute |
| Motor | 12V DC-4A |
