Description
Aardwolf DC Powered Vacuum Lifter (Dual System) ARGL an Electrical Vacuum Lifter for the Lifting and Handling of Stone
The original ARGL-500 is also avialable
The DC Powered Vacuum Lifter (Dual System) ARGL-500DS is an electrical vacuum lifter with a 4-bar tilting mechanism. Integrated with a multi-angle rotation feature, the ARGL-500DS ensures flexibility when vertically rotating and tilting large glass sheets. The ARGL-500DS is equipped with two independent vacuum circuits, which support each other in the event of a system failure to ensure user safety during the working process.
Features
- Double redundancy with a load capacity of 500kg
- Spring-loaded suction pads
- 360 degree rotation with 45 degree steps
- Four extension arms with the ability to extend and retract
- Two independent vacuum circuits provide mutual aid in the event of a system error
- Automatic vacuum pumping system
- Audio and visual warning system
- 12V power supply by a high-capacity battery
Specifications
| Metric (mm-kg) |
Imperial (inch-lbs) |
|
| Number of pads | 8 | – |
| Pad diameter | 300 | 11.8 |
| Working load limit | Vertical: 400 Horizontal: 500 |
882 1102 |
| Net weight | 83 | 183 |
| Gross weight | 103 | 227 |
| Packaging dimension | 1070x980x540 | 42.1×38.6×21.3 |
