Description
Aardwolf Mono Mechanical Vacuum Lifter 650
No power source required. Ideal for the horizontal handling of non-porous sheet and plate material such as diamond sawn or polished granite, engineered stone, all types of metals, plastics and fiberglass. An automatic self-cycling valve located in the bottom of the piston controls the vacuum grip-and-release cycle.
Features
Self-powered and self-cycling
Audio alarm system powered by a non-rechargeable 9V battery
Vacuum gauge for a visual warning of low vacuum
Aluminum construction
Telescopic front handle
Lightweight
Specifications
| Metric (mm-kg) |
Imperial (inch-lbs) |
|
| Number of pads | 1 | – |
| Pad diameter | Seal to seal: 450 | 17.7 |
| Working load limit | 650 | 1433 |
| Net weight | 36 | 79 |
| Gross weight | 64 | 141 |
| Packaging dimension | 1020x560x900 | 40x22x35.4 |
Note: For materials with a rough surface texture, such as exfoliated granite, concrete and textured metals, refer to our electric or air powered vacuum lifters with foam rubber pads.
