Calibre UH-1200 12 Inch CTC Universal Multi-sized Offset Pull Handle

Description

■ Standard 12” CTC Offset Pull Handle with Press Fitting End Brackets.
■ On site adjustment (cutting of stanchion) to match any existing
installation centerline hole dimensions from 12” CTC to 4” CTC.
■ Stanchion Bar is 6063 T5 extruded aluminum with a Class 1 anodized
electrolytic finish.
■ Press fitting End Brackets are a 380 aluminum die cast alloy with a high
quality thermosetting polyester powder coated finish.
■ Universal 1/4-20 fasteners are included for Thru-Bolt, Concealed, and
Back-to-Back installations. Includes 2 each countersunk Trim Washers.
■ Finishes available:
AL – Aluminum with Black End Brackets
