Hager Hardware 9710HD Series 250lb Wall Mount Sliding door Hardware Clear or Black Aluminum 3 Sizes

Description

Hager Hardware 9710HD Series 250lb Wall Mount Sliding door Hardware Clear or Black Aluminum 3 Sizes

NOTE 96″ AND LONGER WILL REGUIRE ADDITIONAL FREIGHT, YOU WILL BE CONTACTED BEFORE SHIPPING TO AGREE TO THE ACTUAL FREIGHT OR THE ORDER WILL BE CANCELLED!

SPECIFICATIONS
Applications
Architecturally designed wall-mount for sliding door hardware for commercial and residential

Available Sizes
9710HD-72CLA – 72″ (1829 mm) for 1 door
9710HD-96CLA – 96″ (2438 mm) for 1 door
9710HD – 144CLA – 144″ (3658 mm) for 1 or 2 doors
Case Quantity
1
Code Compliance
Meets performance ANSIBHMA A156.14 (Grade 1) for sliding doors exceeding 100,000 cycles

Door Thickness
Doors 1-1/8″ to 1-3/4″ thick

Finishes
Clear Anodized, BLK

Maximum Door Weight
250 lbs.

Notes
End Cap Set: Includes embossed Hager logo
Dimension from top of door to the top of hardware: 2-15/15″ to 3-7/16″
Optional Features
Optional Soft-Close (1-269-8651) Item # 27589 for doors up to 150 lbs.

Product Description
Wall-Mount Packaged Set for 1 Door 72″ and 96″
Wall-Mount Packaged Set for 1 or 2 Doors 144″

9710HD Instructions
