Description
Install Manual
Intermatic WHAVQ4 24 Hour 120-240V Water Heater Timer with Battery Backup and Auto-voltage, 40A SPDT/DPDT, Type 3R Indoor/Outdoor Plastic Enclosure
WHAVQ Series Water Heater Timers are designed for control of residential or commercial electric water heaters up to 10,000 Watts capacity running at 240 VAC. The unit is mounted in a UL Type 3R Outdoor enclosure and can be placed in basements or mechanical rooms.
Features:
- 40 A rating
- Self-recharging battery backup with 7-day carry-over
- Captive trippers – cannot be lost
- 24-hour or 7-day models available
- Three-way ON/OFF/AUTO manual override
- Power and status LED indicators
- Rainproof UL Type 3R enclosure
- Saves energy by shutting water heaters OFF during “off peak periods”
- Autovoltage selection 120-240 VAC
- Easy-to-read clock face
Applications:
- Water Heater Control
Specifications:
| Backup Type | 72-hour Carry-over, Battery, Self-recharging | Input Voltage Range(s) | 120-240 VAC, 50/60 Hz |
| Maximum ON/OFF Operations | 48 | Operation Mode | 24 hour |
| Switch Type | 40 A, DPDT | Enclosure Type | Indoor/outdoor type 3R plastic |
| Has Real-time Clock Face | Yes | Mechanism Type | Electromechanical |
| Resistive (NO) | 40 A, 250 VAC, 10,000 W | Warranty Period | 1-Year limited |
| Wiring Option | Screw box lug | Backup Protection Time | 72 Hours |
| Battery Service Type | Rechargeable | Category | Timer Controls Web |
| Electrical Life | 50,000 operations at full load | Has Captive Trippers | Yes |
| Has Override Switch | Yes | Motor (NC) | 1 HP, 12 FLA, 30 LRA @120 VAC, 2 HP, 10 FLA, 30 LRA @240 VAC |
| Motor (NO) | 1 HP, 16 FLA, 90 LRA @ 120 VAC, 2 HP, 12 FLA, 52 LRA @ 208-277 VAC | Number of Trippers Included | 96 |
| Operating Humidity | 0-95% RH, Non-condensing | Resistive (NC) | 30 A, 250 VAC, 7500 W |
| RoHS Certification | Yes | Switch Configuration | DPDT (2 NO and 2 NC contacts) |
| Switch Rating For NC | 30 A Resistive, 250 VAC, 7500 W | Switch Rating For NO | 40 A Resistive, 250 VAC, 10,000 W |
| Tungsten (NC) Load Ratings | 2 A, 120 VAC, 50 Hz, 2 A, 120 VAC, 60 Hz | Tungsten (NO) Load Ratings | 15 A, 120 VAC, 50 Hz, 15 A, 120 VAC, 60 Hz |
| Voltage Selection Type | Auto Voltage | Wire Size Max | #8 AWG |
| Operating Temperature Max (°C) | 40 | Operating Temperature Max (°F) | 104 |
| Operating Temperature Min (°C) | -20 | Operating Temperature Min (°F) | -4 |
| Unit Carton Height (in) | 9.125 | Unit Carton Length (in) | 6.75 |
| Unit Carton Weight (lb) | 1.9 | Unit Carton Width (in) | 3 |
Specs
Backup Type72-hour Carry-over, Battery, Self-rechargingInput Voltage Range(s)120-240 VAC, 50/60 Hz
Maximum ON/OFF Operations48Operation Mode24 hour
Switch Type40 A, DPDTEnclosure TypeIndoor/outdoor type 3R plastic
Has Real-time Clock FaceYesMechanism TypeElectromechanical
Resistive (NO)40 A, 250 VAC, 10,000 WWarranty Period1-Year limited
Wiring OptionScrew box lugBackup Protection Time72 Hours
Battery Service TypeRechargeableCategoryTimer Controls Web
Electrical Life50,000 operations at full loadHas Captive TrippersYes
Has Override SwitchYesMotor (NC)1 HP, 12 FLA, 30 LRA @120 VAC, 2 HP, 10 FLA, 30 LRA @240 VAC
Motor (NO)1 HP, 16 FLA, 90 LRA @ 120 VAC, 2 HP, 12 FLA, 52 LRA @ 208-277 VACNumber of Trippers Included96
Operating Humidity0-95% RH, Non-condensingResistive (NC)30 A, 250 VAC, 7500 W
RoHS CertificationYesSwitch ConfigurationDPDT (2 NO and 2 NC contacts)
Switch Rating For NC30 A Resistive, 250 VAC, 7500 WSwitch Rating For NO40 A Resistive, 250 VAC, 10,000 W
Tungsten (NC) Load Ratings2 A, 120 VAC, 50 Hz, 2 A, 120 VAC, 60 HzTungsten (NO) Load Ratings15 A, 120 VAC, 50 Hz, 15 A, 120 VAC, 60 Hz
Voltage Selection TypeAuto VoltageWire Size Max#8 AWG
Operating Temperature Max (°C)40Operating Temperature Max (°F)104
Operating Temperature Min (°C)-20Operating Temperature Min (°F)-4
Unit Carton Height (in)9.125Unit Carton Length (in)6.75
Unit Carton Weight (lb)1.9Unit Carton Width (in)3
