Rain Bird – BPUMP1HP – 1HP Booster Pump

Description

Spec Sheet  Install Manual

Built for continuous operation for lawn sprinkling and water feature applications, Rain Birds self-priming centrifugal booster pumps are perfect in applications where up to 66gpm are needed. Our pumps are 100% balanced at the factory for industry-leading quiet operation, and every pump is factory tested to ensure plumbing and electrical systems are performing correctly.

*All pumps must be primed (filling the cavity with water) before they are first operated

Quick install and fewer points of failure reducing your time on the job and callbacks

• Quick self-priming operation for lawn irrigation *All pumps must be primed (filling the cavity with water) before they are first operated
• Standard 2″ Inlet reduces the need for additional pipe adapters and potential points of failure
• 115/230 dual voltage motor for maximum flexibility

Built tough in the USA using a majority of U.S. content

• Heavy-duty cast-iron construction
• Motor featuring capacitor assisted start up and 2 oversized self-lubricating ball bearings for quiet continuous operation
• Chemical and abrasion resistant fiberglass reinforced thermoplastic impeller
• Cool running motor is engineered for continuous operation in ambient temperatures up to 145 F (65c)

Constructed with ease of maintenance in mind

• 4 bolts remove the motor for easy maintenance without disconnecting piping
• Easy access drain plug

Specifications

• Impeller: Fiberglass reinforced thermoplastic
• Flows To: 66 GPM (250 LPM)
• Inlet and Outlet: 2″ FNPT suction port / 1½” FNPT discharge port
• One-year trade warranty

Motor Specs

• Single Phase
• 115/230 dual voltage motor
• 60 Hertz
• 3,540 RPM
• Max Amps: 230v: 9amps | 115v: 18amps

Applications

• Well
• Buried Cistern
• Lake and Ditchwater
• Gravity-fed above ground water source
• Boosting municipal water source

Specs

Single Phase
115/230 dual voltage motor
60 Hertz
3,540 RPM
Max Amps: 230v: 9amps | 115v: 18amps
