The ESP-2WIRE Controller and 2W-1 Decoder (sold Separately) continue Rain Bird’s legacy of the best-in-class 2-wire experience with an approachable platform for projects up to 50 stations.
With new Decoder Auto-Address functionality all decoders connected to the 2-wire path are found and assigned to stations providing significant time savings. After decoders are programmed, the ESP-2WIRE Controller programs just like the popular ESP-ME3 Controller.
With no special wire, wire connector or grounding requirements, contractors can now take advantage of all 2-wire benefits with a familiar platform that’s easy to install and program.
Features
50-Station capacity standard without the need for expansion modulesCompatible with standard direct burial irrigation wire and standard irrigation wire connectorsDecoder Auto-Address to detect and assign decoder addresses to stations automaticallySupports up to two 2-wire pathsDiagnostic LEDs on the back plane and on each 2W-1 Decoder for advanced troubleshooting4 available programs with up to 6 start times for each program to meet the needs of varied landscapes One-touch manual watering capability for ease of useLarge back-lit LCD display for improved visibility in low-light and direct sun conditionsContractor Default™ allows you to easily save and restore your custom scheduleDelay Watering up to 14 days and automatically resume watering after the set delay has elapsedBypass Rain Sensor for any station gives you the ability to customize which stations react to a rain sensorSeasonal Adjust by program allows you to easily reduce or increase watering by programUpgradeable for WiFi-based remote monitoring and control via iOS and Android mobile devices (with LNK2 WiFi Module sold separately) Internet-based weather information can be used to make daily adjustments to the irrigation schedule, saving up to 30% in water (with LNK2 WiFi Module sold separately)Set Permanent Days Off per program to ensure watering never occurs on days when maintenance crews are on site (for Odd/Even/ Cyclic schedules)Easy to install indoors or outdoors with pre-installed power cord
Specs
Operating SpecificationsOperating Temperature: Up to 149°F (65°C)Electrical SpecificationsInput required: 120VAC (+/- 10%), 60Hz, (International models: 230VAC (+/- 10%), 50Hz)Output: 1.0A at 25.5VACMaster Valve/Pump Start RelayExternal battery back-up not required. Nonvolatile memory permanently saves the current programming and a 10 year life lithium battery maintains the controllers time and date during power outages.Certifications120V Models: cULus [US and Canada], FCC Part 15 [US], NOM-001-SCFI-2018 [Mexico]230V Models: CE, UKCA, RCM, IRAM, CMIM, NRCS, ECASIPX4WaterSense certified with up to 30% water savings when installed with Rain Bird LNK2 WiFi Module and WR2 Rain Sensor
Dimensions
Width: 10.7 in. (27.2 cm) Height: 7.7 in. (19.5 cm) Depth: 4.4 in. (11.2 cm)
Accessories
2W-1 Decoder: Compatible decoder for ESP-2WIRE ControllerLNK2 WIFI: LNK2 WiFi Module for remote control and notification via iOS or Android device FG100: Flow SensorWR2-RFC: Rain + Freeze ComboWR2-48: Rain + Freeze Combo with 48-hour holdRSD-BEx: Rain sensor w/ latching bracket, extension wireSpecs
Operating Specifications
Operating Temperature: Up to 149°F (65°C)
Electrical Specifications
Input required: 120VAC (+/- 10%), 60Hz, (International models: 230VAC (+/- 10%), 50Hz)
Output: 1.0A at 25.5VAC
Master Valve/Pump Start Relay
External battery back-up not required. Nonvolatile memory permanently saves the current programming and a 10 year life lithium battery maintains the controllers time and date during power outages.
Certifications
120V Models: cULus [US and Canada], FCC Part 15 [US], NOM-001-SCFI-2018 [Mexico]
230V Models: CE, UKCA, RCM, IRAM, CMIM, NRCS, ECAS
IPX4
WaterSense certified with up to 30% water savings when installed with Rain Bird LNK2 WiFi Module and WR2 Rain Sensor
Dimension
Width: 10.7 in. (27.2 cm)
Height: 7.7 in. (19.5 cm)
Depth: 4.4 in. (11.2 cm)
