Rixson EH28 – Center Hung, Single Acting, Thru-Wire/Power Transfer

Description

MODEL EH28 | CENTER HUNG, SINGLE ACTING FLOOR CLOSER

The Norton Rixson EH28 Series is a single-acting, center-hung floor closer designed for power transfer from the frame to the door through the closer spindle for interior or exterior doors weighing up to 500lbs.

PRODUCT FEATURES

• EH28 floor closer, non-hold open
• Single acting, handed
• Exterior or interior doors weighing up to 500 lbs.
• H340 top pivot included
• Available non-hold open (N) or selective hold open (S) at the same degree as dead stop
• Built-in positive dead stop prevents doors from swinging beyond the desired opening degree; specify 85°, 90°, 95°, or 105°
• Provides power transfer through closer spindle; low voltage, class II wiring (2 wire, 18 gauge only)
• Separate and independent valves for closing speed, latch speed, and backcheck
• Cast iron cement case
• Not allowed for fire-rated doors
• Frame stop required on the header at lock side; if not supplied by the frame manufacturer, Norton Rixson 60131 recommended
• 2″ minimum door thickness
• 587 is a special side load arm for 1-3/4” thick doors; this arm allows the pivot point to be moved away from the pivot edge of the door – minimum 2-3/4” backset
• Available with floor plate or threshold installation
• Furnished with wood and machine screws
• Door sizes up to 4’0″ x 8’6″ (1219 x 2591mm)
