Schlage Privacy Elan Lever Door Lock with Standard Trim

Description

Schlage Privacy Elan Lever Door Lock with Standard Trim

F-Series Levers/Knobs
Certification: ANSI/BHMA A156.2-2017 Commercial Grade 2
ANSI/BHMA A156.39-2015 Residential Grade AAA
Available UL Listed for 3-hour fire door (F10, F40, F51A, F80 functions)
Latch: 1”x 2 1/4”, 1/4” radius corner faceplate, 7/8” housing diameter, 1/2”
throw, circular drive-in included, universal latch
Strike: 1 5/8” x 2 1/4” radius corner, full lip, no box
Backset: Dual backset latches, fits either 2 3/8” or 2 3/4” backsets
Door Range: 1 3/8” – 1 3/4”

Spring Latch 16-080 -Dual Option (Round, Drive-in)

Strike 10-027 -Round Corner Full Lip
