Description
The ED-301 “crash bar” style exit device are suitable for narrow, medium, or wide stile aluminum and hollow metal doors. It is designed for all heavy duty commercial and industrial applications. It is non-handed with a contoured cross bar that will fit doors up to 36″ and can be field measured to accommodate narrow doors.
Specifications ED-301
ANSI A156.3 Grade 2
Contoured aluminum
Stainless Steel springs
Latch Case: 1 1/4″ w x 7 1/4″ l with 1/2″ throw Backset: 1 5/32″
Strike: rim mounted roller strike with shim Projection: 4 1/2″
Stile: 2″ minimum
Non handed
Door thickness: 1 3/4″ standard
Door width: up to 36″ and shoulder mounting studs with set screws.
Thumbturn dogging
Warranty: 1 Year mechanical and finish warranty
Finishes: AL, DU
The ED-VR331 panic devices blend the utility of a vertical rod application with the appearance of a traditional panic device. it is non-handed and reversible with a contoured cross bar that will fit doors up to 36″.
Specifications ED-VR331
ANSI A156.3 Grade 2
Contoured aluminum
Interlocking top and pullman bottom latch
Non handed
Door thickness: 1 3/4″ standard
Door width: up to 36″
Door height: up to 7′
Fasteners: furnished with sheet metal, machine screws and shoulder mounting studs with set screws. 12″ Extension Rod available
Warranty: 1 year
Finishes: AL, DU
