421815 – Mavrik – 25 – 50 PSI Low Pressure Switch

Description

Specifications

• Ship Weight : 0.12 LBS.
• Height (in) : 2
• Length (in) : 5.25
• Psi : 25 – 50
• Voltage (V AC) : 24/120/240
• Width (in) : 3

DescriptionAutomatic Reset High, Low & Condenser Fan Cycling Pressure Switches. LOW PRESSURE OPEN 25 PSI, CLOSE 50 PSI, +/- 15 PSI High pressure SPST open on pressure rise Low pressure SPST open on pressure fall Condenser fan cycling SPST open on pressure fall. 1/4″ female SAE connection Snap acting SS hermetically sealed sensor (SHP, SLP & SFC) Small size and light weight for direct mounting Excellent set point repeatability/stability Pressure range: 0 to 650 PSI, Burst pressure: 5000 PSI Life @ rated load: 100,000 cycles Rated voltage: 50/60 Hz., 24/120/240 V (6 RLA, 36 LRA) Temperatures: ambient 20°F to 176°F (-30°C to 80°C) Fluid 60°F to 250°F (-50°C to 120°C)
